LIFTING LOOPS
Lifting Loop
Lifting loops are a lifting system designed for lifting precast concrete units where the lifting points will be hidden once installed in its final position.
The lifting loops are designed and manufactured in accordance with EU Machinery Directive 2006/42/EC and VDI/BV-BS 6205. The standard wire loops meet the requirements for safe lifting and handling of concrete elements.
Surface treatment: Electro galvanised or A4 Stainless steel
Material insert: S355J2 or A4 Stainless steel
All items are:
- CE Marked
- With traceability no
- Delivered with 3.1 certificate
- Can be delivered as private label
Material: High strength lifting loops
Thread Type: RD thread / M thread
Safe Factor: 4:1
Product specifications
| Size | H1 | H2 | Φd | L | SWL (TON) |
|---|---|---|---|---|---|
| M12 | 32 | 20 | 6 | 155 | 0.5 |
| M14 | 40 | 22 | 7 | 155 | 0.8 |
| M16 | 40 | 23 | 8 | 155 | 1.2 |
| M18 | 50 | 28 | 9 | 190 | 1.6 |
| M20 | 50 | 31 | 10 | 215 | 2.0 |
| M24 | 60 | 38 | 12 | 255 | 2.5 |
| M30 | 85 | 50 | 16 | 300 | 4.0 |
| M36 | 90 | 60 | 18 | 340 | 6.3 |
| M42 | 100 | 68 | 20 | 425 | 8.0 |
| M52 | 110 | 86 | 26 | 550 | 12.5 |
